External Turning Toolholders MWLN R/L
External Turning Toolholders MWLN R/L
|
Ordering Code |
Item Designation |
Dimensions (mm) |
Master Insert* |
||||
|
Direction |
MWLN R/L (95) |
h=H |
b |
L |
f |
|
|
|
Right |
Left |
||||||
|
STEP
SM01428 |
STEP
SM01435 |
MWLN R/L 1616 H06 |
16 |
16 |
100 |
20 |
WNM.0604.. |
|
STEP
SM01459 |
STEP
SM01466 |
MWLN R/L 2020 K06 |
20 |
20 |
125 |
26 |
|
|
STEP
SM01473 |
STEP
SM01480 |
MWLN R/L 2525 M06 |
25 |
25 |
150 |
32 |
|
|
STEP
SM01534 |
STEP
SM01497 |
MWLN R/L 2020 K08 |
20 |
20 |
125 |
26 |
WNM.0804.. |
|
STEP
SM01558 |
STEP
SM01572 |
MWLN R/L 2525 M08 |
25 |
25 |
150 |
32 |
|
|
STEP
SM01602 |
STEP
SM01589 |
MWLN R/L 3232 P08 |
32 |
32 |
170 |
38 |
|
|
STEP
SM01527 |
STEP
SM25776 |
MWLN R/L 4040 S08 |
40 |
40 |
250 |
47 |
|
|
Size Designation |
Master Insert* |
Spare Parts |
|||||
|
|
Clamp |
Screw |
Shim |
Pin |
Spring |
Allen Key |
|
|
|
|
|
|
|
|
||
|
1616 |
WNM.0604.. |
MSK4-9110 |
TSBV M5x18-9201 |
BAX WN06-9606 |
BMP5 3.70x5x13 9312 |
– |
SAK-AA3-9902 |
|
2020 – 2525 |
|||||||
|
2020 – 4040 |
WNM.0804.. |
MSK3-9109 |
TSBV M6x30 9205 |
BAX WN08 9607 |
BMP3 5x6x17 9311 |
TSP 6.5X12 9705 |
|
