Turning Inserts ISCAR SNMM
ISCAR CARBIDE INSERTS SNMM
- SNMM 120408
- SNMM 120412
- SNMM 120416
- SNMM 150612
- SNMM 150616
- SNMM 190612
- SNMM 190616
- SNMM 190624
- SNMM 250724
- SNMM 250924
| Grade | Coating | App Range | 05 | 10 | 15 | 20 | 25 | 30 | 35 | 40 | 45 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| P – Steel | |||||||||||
| IC807 (IC907) | PVD | P05 – P25 | P | P | P | P | P | ||||
| IC8150 | CVD | P10 – P15 | P | P | |||||||
| IC8250 | CVD | P15 – P30 | P | P | P | P | |||||
| IC830 (IC328) | PVD | P25 – P45 | P | P | P | P | P | ||||
| M – Stainless Steel | |||||||||||
| IC807 (IC907) | PVD | M05 – M20 | M | M | M | M | |||||
| IC6015 | CVD | M05 – M15 | M | M | M | ||||||
| IC6025 | CVD | M15 – M35 | M | M | M | M | M | ||||
| IC830 (IC328) | PVD | M20 – M45 | M | M | M | M | M | M | |||
| K – Cast Iron | |||||||||||
| IC807 (IC907) | PVD | K05 – K25 | K | K | K | K | K | ||||
| IC5005 | CVD | K05 – K15 | K | K | K | ||||||
| IC5010 (IC428) | CVD | K10 – K25 | K | K | K | K | |||||
| IC8150 | CVD | K25 – K35 | K | K | K | ||||||
| IC830 (IC328) | PVD | K25 – K45 | K | K | K | K | K | ||||
| N – Non-Ferrous | |||||||||||
| IC20 | Uncoated | N05 – N30 | N | N | N | N | N | N | |||
| S – Superalloys | |||||||||||
| IC806 (IC804) | PVD | S05 – S20 | S | S | S | S | |||||
| IC807 (IC907) | PVD | S10 – S25 | S | S | S | S | |||||
| IC830 (IC328) | PVD | S20 – S35 | S | S | S | S | |||||
Technical details are available on request.
ISCAR is a dynamic full line supplier of precision carbide metal working tools, producing a wide range of carbide inserts, carbide end mills and cutting tools
