External Turning Toolholders TCRN R/L
External Turning Toolholders TCRN R/L
|
Ordering Code |
Item Designation |
Dimensions (mm) |
Master Insert* |
||||
|
Direction |
TCRN R/L (75) |
h=H |
b |
L |
f |
|
|
|
Right |
Left |
||||||
|
STEP
SM00388 |
STEP
SM00395 |
TCRN R/L 2020 K12 |
20 |
20 |
125 |
26 |
CNM.1204.. |
|
STEP
SM00401 |
STEP
SM00418 |
TCRN R/L 2525 M12 |
25 |
25 |
150 |
29 |
|
|
STEP
SM00432 |
STEP
SM00449 |
TCRN R/L 2525 M16 |
25 |
25 |
150 |
28.5 |
CNM.1606.. |
|
STEP
SM00456 |
STEP
SM00463 |
TCRN R/L 3232 P16 |
32 |
32 |
170 |
34.5 |
|
|
Size Designation |
Master Insert* |
Spare Parts |
|||||
|
|
Clamp |
Screw |
Shim |
Shim Screw |
Stamp |
Allen Key |
|
|
|
|
|
|
|
|
||
|
2020 – 4040 |
CNM.1204.. |
TSK1-9101 |
TSBV M6x30-9205 |
BAX CN12-9603 |
TSAV M4x10-9403 |
TSP 6.5×12-9705 |
SAK-AA3-9902 |
|
2525 – 4040 |
CNM.1606.. |
TSK3-9103 |
TSBV M6x30x7-9206 |
BAX CN16-9604 |
TSAV M6x16x9-9404 |
– |
|
|
3232 – 4040 |
CNM.1909.. |
TSK4-9104 |
TSBV M8x30-9207 |
BAX CN19-9605 |
TSAV M6x16x11-9406 |
SAK-AA4-9903 |
|
