Steel Wire Ropes - 6×7-WSC
Steel Wire Ropes – 6×7-WSC
Steel wire ropes with point contact of the wires
PRODUCT TECHNICAL DATA
Rope diameter: from 2,5 mm to 20,0 mm
Strand design: 6×7-WSC
Strand design: 6x(1-6)+1x(1-6)
Core: WSC
Execution standards: DIN 3055 / EN 12385-4
Tensile strength range: 1770 N/ – 1960 N/mm2
Zinc coating: Class B*
| Nominal rope diameter [mm] | Approximate nominal weight [kg/100m] | Minimum breaking load [kN] 1960 N/mm2 |
|---|---|---|
| 2,5 | 2,40 | 4,40 |
| 2,8 | 3,01 | 5,52 |
| 3,2 | 3,93 | 7,21 |
| 3,6 | 4,98 | 9,12 |
| 4,0 | 6,14 | 11,26 |
| 4,5 | 7,78 | 14,2 |
| 5,0 | 9,60 | 17,6 |
| 5,5 | 11,6 | 21,3 |
| 6,3 | 15,2 | 27,9 |
| 7,0 | 18,8 | 34,5 |
| 8,0 | 24,6 | 45,0 |
| 9,0 | 31,1 | 57,0 |
| 10,0 | 38,4 | 70,4 |
| 11,0 | 46,5 | 85,1 |
| 12,0 | 55,3 | 101,3 |
| 13,0 | 64,9 | 118,9 |
| 14,0 | 75,3 | 137,9 |
| 16,0 | 98,3 | 180,1 |
| 18,0 | 124,4 | 228,0 |
| 20,0 | 153,6 | 281,5 |
*on request, we produce ropes from ungalvanized wires (without zinc coating) and from heavily galvanized wires – class A
