SIEMENS SIRIUS 3RT2035 - 3RT2038 Contactors

SIEMENS SIRIUS 3RT2035, 3RT2036, 3RT2037 AND 3RT2038 Contactors

Siemens Sirius motor starter contactors have high contact reliability, a narrow design, long life time, and the ability to operate under extreme conditions. This flexibility ensures that Sirius 3RT Contactors are suited for almost any application. A large array of easily installed, standard accessories may be used to customize the contactors different applications.

3RT203 AC CONTACTORS, FRAME SIZE S2

Photo	Amp Ratings		Three Phase HP Ratings		Catalog No.
	AC3	AC1	230V	460V	Screw Terminals	Spring Loaded Terminals
3RT2035-1AC20	40	60	15	30	3RT2035-1A..0	3RT2035-2A..0
					24V   3RT2035-1AC20	3RT2035-2AC20
					120V  3RT2035-1AK60	3RT2035-2AK60
					240V   3RT2035-1AP60	3RT2035-2AP60
					3RT2036-1A..0	3RT2036-2A..0
	50	70	15	40	24V   3RT2036-1AC20	3RT2036-2AC20
					120V  3RT2036-1AK60	3RT2036-2AK60
					240V  3RT2036-1AP60	3RT2036-2AP60
3RT2037-1AC20	65	80	20	50	3RT2037-1A..0	3RT2037-2A..0
					24V   3RT2037-1AC20	3RT2037-2AC20
					120V  3RT2037-1AK60	3RT2037-2AK60
					240V   3RT2037-1AP60	3RT2037-2AP60
					3RT2038-1A..0	3RT2038-2A..0
	80	90	25	50	24V   3RT2038-1AC20	3RT2038-2AC20
					120V  3RT2038-1AK60	3RT2038-2AK60
					240V  3RT2038-1AP60	3RT2038-2AP60

3RT203 DC CONTACTORS, FRAME SIZE S2
