Mechanical Rail track Jack
Mechanical Rail track Jack
For lifting and lowering loads, such as track panels or rails.
- Durable, stable and robust
- Safe stand on large, reinforced foot plate
- Crank with load pressure brake and folding handle
Technical data
| Max. lifting capacity | 3 t | 5 t | 7.5 t | 10 t |
| Max. lifting height | 340 mm | 300 mm | 300 mm | 300 mm |
| Partial lift per ratchet | 0.8 mm | 0.4 mm | 0.4 mm | 0.3 mm |
| Lift per crank handle turn | 8 mm | 4 mm | 4 mm | 4 mm |
| Excavation height | 65 mm | 65 mm | 65 mm | 80 mm |
| Dimensions (L x W x H) | 290 x 220 x 715 mm | 290 x 230 x 720 mm | 290 x 230 x 720 mm | 335 x 260 x 790 mm |
| Total Weight | ~24.5 kg | ~29.5 kg | ~34 kg | ~46 kg |
