Electrohydraulic Thrusters MAGNETEK ED 121/6

Our company offers a wide range of thrusters that can easily fit into your existing brake system.
They are available in sizes to replace the thrusters used on Bubenzer, Hillmar, Sekarb, Siegerland Bremsen, Hindon, Sibre, GE, ZPMC, Galvi, and Johnson brakes.
We are also your source to repair or rebuild the existing AC Electro-Hydraulic thrusters on your
crane brake systems.

STANDARD FEATURES

• Fast response – 2,000 cycles per hour
• Long service life with minimum maintenance
• Extending forces from 50 lbs. to 900 lbs.
• Strokes from 2 to 7.8 inches
• Can be stalled at any stroke position without damage
• Operating ambient temperature -13°F to +122°F with
standard fluid (other ranges available on request)
• Class F insulation
• Aluminum housings

OPTIONS

• Internal compression spring
• Externally adjustable, stepless time delays —
both directions
• Vacuum poured stator windings
• Special paint for corrosion protection or
easier decontamination
• Internal heaters for below -22°F ambient
(110 Vac or 220 Vac)
• Explosion proof models available in
VDE EEx d II and EEx d I
• Cast iron housings for nuclear applications

THRUSTER VOLTAGE RATINGS

• AC – 208, 230, 380, 460, and 575 Vac
• DC – 220 Vdc standard. 24 Vdc to 500 Vdc available
